Specificaton technology：
|
Model
|
MDZXE6
|
|
Safe working load
|
350kg
|
|
Safe working load for extension platform
|
113
|
|
Max. Working persons
|
2
|
|
Max. Working height(A)
|
8m
|
|
Max. Platform height (B)
|
6m
|
|
Whole machine length(C)
|
2.050m
|
|
Whole machine width(D)
|
0.50%0m
|
|
Whole machine height(fences not folded)
|
2.680m
|
|
Whole machine height(fences
|
1.650m
|
|
Working platform size
|
1.9m*0.9m
|
|
Platform extension size (G)
|
0.9m
|
|
Ground clearance
|
0.1m
|
|
Ground clearance(Lifting condition)
|
0.019m
|
|
wheel base
|
1.89m
|
|
minimum turning radius(inner ones)
|
0
|
|
minimum turning radius ones)
|
2.2m
|
|
Lifting motor driving motor
|
24v/2.2kw
|
|
Machine speed(Folding state)
|
3.4km/min
|
|
Machine speed(Lifting condition)
|
0.8km/min
|
|
The rising / falling speed
|
100/80 sec
|
|
storage battery
|
4×6V/250Ah
|
|
charger
|
24v/25A
|
|
gradeability
|
25%
|
|
The maximum allowable working angle (indoor / outdoor)
|
2°/3°
|
|
tyre
|
Φ305*100
|
|
Machine Weight
|
1280kg
|
Product function：
|
ratio control
|
autobrake system
|
Standard shipping forklift hole
|
The whole trip walk
|
|
Flat tire
|
Emergency descent system
|
trumpet
|
Charging protection system
|
|
Tilt protection system
|
Emergency Stop Button
|
Folding fence
|
4×2 drive
|
Product configuration and material origin：
|
safety guard
|
The 35mm*35mm square
|
|
mesa
|
With Tread plate 2.5mm
|
|
Support rod
|
quarter bend：120mm*60mm*5mm material Q345 manganese steel
|
|
chassis
|
Q345 manganese steel, Steel plate welding
|
|
Link pin
|
Carbon fiber bearing 45
|
|
fluid cylinder
|
Hebei HengYu Japan-China（1pcs）
|
|
power storage battery
|
American TROJAN
|
|
hydraulic fluid
|
KunLun brand N46# wear-resisting
|
|
ECU
|
Delixi
|
|
Motor gear pump
|
Italyimport
|
|
cartridge valve
|
american
|
|
gate lock
|
no
|
|
Tilt switch
|
The joint venture in Shanghai
|
|
pump system
|
Anshan wins Italian joint venture
|
|
tyre
|
Bonded solid tyre, grey
|
|
oil connection
|
The joint venture in Shanghai
|
|
surface preparation
|
Hit the sand spray pickling phosphating
|
