Technology Parameters
|
|
Items
|
ZLP630
|
|
Rated loading capacity
|
630 KG
|
|
Lifting speed
|
9-11m/min
|
|
Suspension platform size (L x W)
|
（2.5m+2m+1.5m）x0.76m
|
|
Steel wire rope
|
Structure: 4 x31sw + NF - 8.3 minimum breaking force: 53 kn
|
|
Elevator
|
Model
|
LTD63
|
|
Hoisting form
|
“a”shape
|
|
rated lifting force
|
6.3 KN
|
|
Motor
|
Model
|
YEJ90L-4
|
|
Power
|
1.5 KW
|
|
Voltage
|
AC 380V
|
|
Braking torque
|
15.2 N.m
|
|
Security lock
|
Type
|
Swing arm type anti tilt
|
|
Model
|
LSF30
|
|
Suspension mechanism
|
Quantity
|
2 sets
|
|
adjustable height
|
1.15-1.75 m
|
|
Front beam overhang
|
1.1 1.7 m (1.5 m and 1.5 m above must be appropriate to reduce weight)
|
|
Quantity
|
Suspension platform (including elevator, safety lock, electric control box)
|
410kg（steel）
|
|
suspension mechanism
|
2x175 kg
|
|
Balance Weight
|
900 kg
|
|
The whole machine (not including wire rope)
|
1700kg (steel)
|
|
Hanging basket normal working environment
|
Environment temperature-20°C- +40°C
|
|
Environment relative humidity≤90%（25°C）
|
|
Power supply voltage deviation rating±5%
|
|
Essence of gust wind acuities were 8.3 m/s wind (equivalent to level 5)
|
